| Model | ETF-M20 | ETF-M30 | |
| Laser Parameters | Output Power | 19 W | 25 W |
| Beam Quality M2 | ≤ 1.4 | ≤ 1.4 | |
| Pulse Repetition Frequency | 27 – 60 kHz | 30 – 60 kHz | |
| Laser Wavelength | 1064 ± 5 nm | ||
| Output Power | < 3% | ||
| Design Life | Approx.100000 Operating Hours (Non-life Time) | ||
| Optical Properties | Marking Range | 100 – 150mm (Range Optional) | |
| Engraving Depth | ≤ 1 mm (Depending on Power and Time) | ||
| Engraving Speed | ≤ 10000 mm/s | ||
| Repetition Accuracy | ± 0.002 | ||
| Minimum Marker Line Width | 0.1 mm | ||
| Minimum Character Height | 0.15 mm | ||
| Use Environment | Cooling Method | Built-in Air Cooling | |
| System Power Supply | 500 W / 220 V / 50 Hz(Can be Connected to 110 V) | ||
| Temperature, Humidity | 0-40°,30% RH 85%, need to install air conditioning when using beyond the range | ||
| Oil mist, Condensation | Not Allowed | ||
| Other Parameters | Support System | Windows Operating System | |
| External Dimensions | 330 X 275 X 520 mm | ||
| Packing Size | 537 X550 X 200 mm | ||
| Weight of The Whole Machine | Approx. 8.2kg | ||
Intelligent Small Laser Marking Machine – ETF – M 20/30
The ETF-M20/30 desktop fiber laser marking machine offers compact, portable design with performance comparable to larger models. Ideal for economic applications, it’s perfect for various laser marking needs, providing flexibility and convenience.
Details
Intelligent Small Laser Marking Machine – ETF – M 20/30
The ETF-M20/30 is a compact and portable desktop fiber laser marking machine. It’s designed for economic applications, offering flexibility and convenience. Despite its small size and lightweight design, it provides marking performance comparable to larger desktop machines, suitable for most common laser marking needs.
Specifications
ETF-M20/30 intelligent small laser marking machine belongs to the desktop fiber laser marking equipment, the equipment simple and compact，flexible and convenient demand for thedevelopment of economic models. The whole machine is small and easy tocarry, compact and solid, can be disassembled and folded， easy to carry, its marking performance iscomparable to desktop machines, can easily meet most common laser marking applications.
ETF-M20/30 products utilize a 1064nm wavelength fiber laser, making them suitable for marking various metal materials, including iron, copper, aluminum, gold, and silver, as well as certain non-metallic materials such as PC, ABS, PVC, and PC+ABS.
They are widely used in industries such as 3C electronics, automotive parts, electronic components, integrated circuits (PC), electrical appliances, precision instruments, hardware products, construction materials, watches, jewelry, and handicrafts.
Compact and Portable
- Only about 8.2kG
- Small compact andlight
- Easy to install
- Convenient storag
Cost-effective
- Better value for money
- One integrated design
- Stable perfornce
High Quality Light Source
- Advanced fiber laser,
- Good output beam quality
- High reliability
- No consumables
Simple and Flexible Operation
- Support windows system
- Support multi-language
- Easy to learn operation
